It's for switching AC power source from 24V to 480V. The control signal is 3-32V DC. Maximum AC current 25A. Please note it needs a heatsink to work with it.
| Description | 25A SSR |
| Manufacture | Golander |
| Manufacture’s Part Number | GL-DA25 |
| Input Voltage | 3-32VDC |
| Input Current | DC3-25mA |
| Output Voltage | 24-480VAC |
| Current Rating | 25A |
| Output | Triac |
| On Voltage | ≤1.5V |
| Off Leakage Current | ≤2mA |
| On-off Time | ≤10mS |
| Dielectric Strength | 2500VAC |
| Insulation Resistance | 1000MΩ/500VDC |
| Ambient Temperature | -30~+75 ℃ |
| Switch method | zero-cross turn on |
| Dimension | 2.25 x 1.75 x 1.25 (inch) , 57 x 32 x 45 (mm) |
| Weight | 90g |
| Approval | CE |
